Figure 1.

Comparing external and internal irradiation: the ICRP/ ICRU bag of water model. In case A, external radiation (X-rays or gamma rays) there are 20 events uniformly spaced throughout the tissue and the “absorbed dose” (see text) at any microscopic point is evenly distributed. In case B, for internal irradiation (here from a radioactive particle) there is a very large transfer of energy to a small tissue volume and the concept of “absorbed dose” does not apply.

Thus, in the historic and also the current system of radiation protection, those experts who assess radiation risk, who are termed Health Physicists, calculate the cumulative absorbed dose in Grays, i.e. in terms of the total energy in Joules imparted by the beta electron or alpha particle decays of the internal radionuclide contamination to one kilogram of tissue. For this calculation, the tissue is modelled as water. For example, those whose body contains 100 Bq of Strontium-90 are assessed, for the purposes of radiation protection, as having received a cumulative absorbed dose of 100 x w where w is the “cumulative (absorbed) dose coefficient”, obtained from measurements of the biological half life of the Strontium in the body and the decay energy of each decay in Joules. This number w is to be found in a Table published by the ICRP. In the case of the Strontium-90 contaminated individual, if the person weighed 50 kg, then the mean activity concentration would be 2 Bq/kg. The resulting absorbed dose would then be 2 x 2.8 x 10^-8 (this is the ICRP 72 dose coefficient [3]). In other words, the committed dose is 5.6 x 10^-8 Sv (0.056 μSv). But can this be safely compared with a dose from a chest X-ray (40 μSv ) or from natural background radiation (2500 μSv) or from a high dose acute exposure to gamma rays from an atomic bomb linearly scaled to zero dose (the current way of modelling radiation effects)? This chapter explores this question. It is one which has become increasingly necessary as serious health effects, including cancer and leukemia, have been reported in those exposed to internal radioactivity in areas contaminated by radionuclides released from nuclear sites, weapons testing fallout and accidents like Chernobyl and Fukushima, at very low conventionally calculated “absorbed doses”.

The matter has been discussed in some detail since 1998 by the independent European Committee on Radiation Risk (ECRR) whose reports [4, 5] provide a methodology for assessing health effects through a system of weighting factors based on available data. As more and more evidence emerged after 1995 that something was very wrong with the ICRP absorbed dose approach to internal radiation, the UK government set up a Committee Examining Radiation Risk from Internal Emitters (CERRIE). Since there were (and are) political dimensions to the issue, the committee was composed of scientists and experts from the nuclear industry and the official radiation protection organisations in the UK. Unfortunately the 4-years process ended in acrimony, legal threats to member of the committee, and failure to agree a final report. Two reports were issued [6, 7]. However, there was agreement that there were reasonable concerns about the safety of employing “absorbed dose” for certain internal radionuclide situations, and similar concerns about the safety of the ICRP model were made in 2005 by the French IRSN [8]. The error factor that these discussions led to was believed by different ends of the CERRIE process to be between 10-fold and 1000-fold. More recently, the value put on this error factor by the retired Scientific Secretary of the ICRP at a meeting in Stockholm in 2009 was “two orders of magnitude”. What this means, in our Strontium-90 case above, is that the dose from 100Bq contamination to the whole body is no longer 0.056μSv but may now be between 0.56μSv and 56μSv and the risk of fatal cancer is proportionately increased. To put this in perspective, the mean Sr-90 dose over the period 1959-1963 to individuals in the northern hemisphere was given as about 1 mSv [9]. The ICRP risk model gives a 0.45% per Sievert excess lifetime cancer risk. Epidemiological studies suggest that the cancer “epidemic” which began in the 1980s in areas of high rainfall and fallout is a consequence of the earlier fallout exposures [10]. The weighting of dose necessary to explain this is greater than 300 if calculated from the ICRP absolute risk factor of 0.05/Sv [5, 11]. Many other instances of anomalous health effects from exposure to internal radionuclides require hazard weighting factors of between 100-fold and more than 1000-fold, and these are consequences of mechanisms which will be presented.
